HC1500A-1 Oilless Vacuum Pump | 700W, 210 L/min, CE & ISO 9001

Why Choose the HC1500A-1 Oilless Vacuum Pump

When a medical device manufacturer requires an oilless vacuum pump delivering ISO 8573-1 Class 0 air purity for hospital environments, the HC1500A-1 provides the exact contamination-free performance required. By completely eliminating lubricating oil from the internal compression chamber, this pump prevents harmful hydrocarbon emissions from compromising sterile medical facilities or sensitive pneumatic automation circuits. Technical managers and procurement engineers rely on its continuous-duty capability to maintain highly stable vacuum levels across demanding, multi-shift operational schedules. The absence of oil also means a significant reduction in routine maintenance; there is no need for costly oil changes, no replacement of oil mist filters, and no hazardous waste disposal. This ensures a lower total cost of ownership while maintaining strict environmental compliance.

• Power consumption is strictly controlled at ≤700W at rated pressure for highly efficient 220V/50Hz single-phase operation.
• Delivers a high-capacity vacuum flow rate of 210 L/min at -92Kpa, with an alternative configuration available for 110 L/min at -98Kpa.
• Engineered for quiet operation with noise levels strictly maintained at ≤69dB(A), ideal for noise-sensitive environments.
• Designed to function reliably across a wide operating ambient temperature range from -5℃ to 40℃.
• Features integrated thermal protection that automatically activates at 145±5℃ to prevent motor damage during intensive use.
• Fully certified for international market integration with comprehensive CE, RoHS, and ISO 9001 compliance.
• Built with Motor Insulation Class F to ensure safe, long-term continuous-duty performance without thermal degradation.

Key Technical Specifications

Applications & Industries

The HC1500A-1 oilless vacuum pump is heavily utilized in medical suction and laboratory environments where clean, uncontaminated air is an absolute requirement. In medical facilities, it serves as a central component in surgical suction equipment, aspirators, and dental vacuum systems. The ≤69dB(A) noise level ensures a quiet patient environment, while the oil-free compression prevents any risk of airborne contamination. For laboratory applications, the 210 L/min flow rate efficiently drives high-volume vacuum filtration setups, rotary evaporators, mass spectrometers, and sensitive chromatography sample preparations without introducing hydrocarbon mist into the testing area.

In the industrial manufacturing sector, this pump is a critical driver for high-speed pick-and-place automation systems. The reliable 1400rpm motor speed and stable -92Kpa vacuum pressure allow robotic arms and pneumatic suction cups to securely grip, transfer, and release electronic components, glass panels, or consumer goods without dropping them. Packaging machinery engineers frequently integrate this specific model into modified atmosphere packaging (MAP) lines, blister packaging machines, and vacuum sealing equipment. The strictly oil-free design ensures that food, beverage, or pharmaceutical products are never tainted by mechanical lubricants during the air evacuation process.

Furthermore, the HC1500A-1 functions as a highly efficient CNC vacuum table pump for woodworking, plastics routing, and composite material processing. The 17.5kg net weight and standard 244×127mm installation footprint make it straightforward to mount directly onto the frames of CNC machinery. It provides the necessary continuous hold-down force to keep wood, acrylic, and aluminum panels perfectly flat and secure during precision milling operations, preventing material shifting and reducing scrap rates.

Certifications & Compliance

For OEM buyers and procurement engineers, regulatory compliance is a primary concern when sourcing electromechanical components for global distribution. The HC1500A-1 carries the official CE mark, indicating full adherence to European Economic Area (EEA) health, safety, and environmental protection standards. This ensures that manufacturers integrating this vacuum pump into their medical devices, packaging machinery, or automation equipment can legally export and sell their finished goods throughout European markets without facing costly customs delays or compliance barriers.

Additionally, the pump is fully RoHS compliant, guaranteeing that it is manufactured without hazardous materials such as lead, mercury, hexavalent chromium, or cadmium. This is critical for electronic and medical device manufacturers aiming to meet strict global environmental directives and simplify end-of-life disposal protocols. Our manufacturing facilities operate under stringent ISO 9001 quality management systems. This certification assures B2B buyers that every single pump undergoes rigorous, documented testing for performance consistency, dimensional accuracy (330×167×278mm), and electrical safety. By adhering to ISO 9001 standards, we minimize defect rates, ensure component traceability, and protect your brand's reputation in the marketplace.

Frequently Asked Questions

What is the operating temperature range and thermal protection limit for the HC1500A-1?

This oilless vacuum pump is engineered to operate safely and efficiently in ambient temperatures ranging from -5℃ to 40℃. To protect the Class F insulated motor during demanding continuous duty cycles, the unit features an automatic thermal protection switch that activates at exactly 145±5℃. This safety mechanism prevents overheating, protects internal windings, and significantly extends the operational reliability of the equipment in harsh industrial environments.

Is the HC1500A-1 suitable for high-speed pick-and-place automation?

Yes, it is highly suitable for pick-and-place automation systems. The pump operates at a consistent speed of 1400rpm and delivers a high vacuum flow rate of 210 L/min at -92Kpa (or alternatively 110 L/min at -98Kpa, depending on the specific configuration you require). This highly stable vacuum generation ensures that robotic suction cups maintain a firm, reliable grip on materials, reducing the risk of dropped components and minimizing downtime during rapid manufacturing cycles.

What are the exact installation dimensions and power requirements for OEM integration?

The HC1500A-
