HC1500 Oilless Air Pump | 1500W, 120L/min, 800Kpa, CE Certified

HC1500 Series — AC Oil-Free Air Compressor

Why Choose the HC1500 Oilless AC Air Pump

Picture a plant scaling up production — more filling stations, more packaging lines, more pneumatic tools — where the old air supply runs out of breath and oil changes eat into every shift. When demand climbs past 100L/min, most oil-free piston units hit their ceiling. The HC1500 does not: it delivers the highest output in the HCEM AC range — a powerful 120L/min at 800Kpa — while remaining 100% oil-free and lubrication-free for life. With its twin-cylinder, pressure-parallel-flow head and free-air delivery reaching 210L/min, the HC1500 gives growing operations and demanding OEM machines the flow headroom to keep entire work cells running from one dependable pneumatic core.

Key Features

• 100% Oil-Free Operation — eliminates oil-mist contamination and lubrication maintenance entirely, making it safe for food, beverage, pharmaceutical and laboratory integration where air purity is non-negotiable.
• Highest Output in the Range — delivers a powerful 120L/min at 800Kpa, with free-air delivery of up to 210L/min — enough to feed the most demanding multi-station lines from a single unit.
• Heavy-Duty Twin-Cylinder Design — heads in pressure-parallel-flow configuration share the load for smooth, sustained delivery under continuous operating cycles.
• Built for Continuous Duty — F-class motor insulation and a 17.5kg precision-built frame are engineered for round-the-clock production demands.
• Thermal Safety — integrated thermal protection activates at 145±5°C to prevent motor overheating during intensive operation.
• Global Voltage Flexibility — offered as HC1500A-120/8 (220V/50Hz/1) and HC1500B-120/8 (110V/60Hz/1), so OEMs can standardize one pneumatic platform across regional markets.
• Wide Operating Range — functions reliably in ambient air temperatures from -5°C to 40°C.

Applications & Industries

High-volume production lines — For plants where filling, capping, sealing and pick-and-place stations run simultaneously, the HC1500 provides the flow capacity and pressure stability to keep entire lines moving at full speed. Sustaining 120L/min at a steady 800Kpa, it supports the heaviest simultaneous pneumatic loads without pressure sag — and because the air is 100% oil-free, there is no contamination risk and no lubrication downtime across multi-station operations.

Food, beverage & pharmaceutical processing — Hygiene-critical facilities must keep compressed air free of oil contamination during flushing, packaging, sealing and product handling. An oilless design removes that hazard at the source, while the twin-cylinder parallel-flow layout sustains the higher air demand of automated lines. With F-class insulation and thermal protection, the HC1500 supports extended operating cycles without scheduled lubrication shutdowns.

Centralized systems & heavy OEM equipment — The HC1500 also serves as a central air source for workshops, garages and heavy OEM machinery requiring maximum flow at elevated pressure. With a 330×167×278mm body, a 244×127mm mounting footprint and a net weight of 17.5kg, it integrates into equipment frames and mobile carts while delivering output that rivals far larger installations. Dual voltage options allow manufacturers to standardize their pneumatic design across global markets.

Certifications & Compliance

Procurement engineers and OEM buyers require strict quality assurance and regulatory compliance to mitigate supply-chain risk. The HC1500 is manufactured in an ISO 9001-certified facility, ensuring that every unit rolling off the production line adheres to strict quality management principles — consistent manufacturing tolerances, predictable performance across large-batch orders and a commitment to continuous product improvement for industrial buyers.

Furthermore, the HC1500 series supports CE and RoHS compliance. The CE mark indicates conformity with European health, safety and environmental protection standards, supporting market access for OEMs exporting equipment to the European Economic Area. RoHS compliance confirms the pump is manufactured without restricted hazardous substances such as lead, mercury or cadmium — critical for manufacturers of food-processing and pharmaceutical machinery that must meet environmental directives and ensure end-of-life recyclability of their products.

Frequently Asked Questions

What are the electrical requirements and thermal limits of the HC1500?

The HC1500 is available in two configurations to suit regional power grids: the HC1500A-120/8 operates on 220V/50Hz/1, drawing ≤1500W and running at 1400rpm, while the HC1500B-120/8 requires 110V/60Hz/1, drawing ≤1500W and running at 1700rpm. Both models deliver 120L/min at 800Kpa, feature Class F motor insulation and include built-in thermal protection that triggers automatically at 145±5°C. Capacitor values are 35μF for the 220V model and 120μF for the 110V model. The pump operates safely in ambient air temperatures between -5°C and 40°C.

How is the HC1500 different from lower-flow oil-free models?

The HC1500 is the highest-output model in the HCEM AC oil-free range. Where smaller units deliver 60L/min at 700Kpa, the HC1500 sustains 120L/min at a higher 800Kpa working pressure, with free-air delivery up to 210L/min. If your application currently bottlenecks on flow or needs to feed more workstations as you scale, the HC1500 provides headroom within the same compact frame.

How does the HC1500 mount inside OEM equipment or mobile systems?

The HC1500 is designed for straightforward integration into OEM machinery and carts. Overall dimensions are 330×167×278mm, with a 244×127mm mounting footprint (4×M8 holes) and a net weight of 17.5kg — providing industrial-grade output in a frame that can be bolted directly into equipment structures with minimal modification.

Technical Specifications
