Parameter
| Technical Specification | ||
| Model | HC30C2 | |
| Installation size | 52.4X13.5mm(φ3.3X4) | |
| Vacuum fiow rate | 9.5L/min @-92Kpa | |
| Dimension | 112.5×34×68.7 mm | |
| Nominai voltage input | DC16.8V | |
| Power | ≤18W | |
| Rated speed | ≤1950rpm | |
| Noise | ≤48dB(A) | |
| Packing | 300pcs / pallet | |
| Net weight | 0.395 kg | |
| Use environment | -5℃-40℃ | |
| Accessories | 1x Controller | |
Explosion Diagram
