Parameter
| Technical Specification | ||
| Model | HC280D | |
| Installation size | 83*146 mm | |
| Air fiow rate | 75 L/min@0 bar | |
| 50 L/min@2 bar | ||
| 30 L/min@4 bar | ||
| 21 L/min@6 bar | ||
| 15 L/min@7 bar | ||
| Dimension | 242*104*165 mm | |
| Voltage | DC12V /24V /48V | |
| Power | ≤330W | |
| Rated speed | 1450rpm | |
| Noise | ≤58dB(A) | |
| Packing | 1 pcs / carton case | |
| Net weight | 6.0 kg | |
| Operating ambient air temperature | -5℃-40℃ | |
| Accessories | 1x Controller ,4x Rubber Feet ,1x air Filter | |
| Feature: | Application: | |
| Brushless Motor | Manual Diy | |
| Super Quiet | Oxygen concentrator | |
| long service life | Eletric vehicles | |
| High Quality Material | Solar Pond Aerator | |
