Parameter
| Technical Specification | ||
| Model | HC1100A2 | HC1100A2-1 |
| Installation size | 127*244 mm(M8X4) | |
| Vacuum flow rate | 200L/min @ -93Kpa | |
| 100 L/min@-98Kpa | ||
| Dimension | 330*167*278 mm | |
| Voltage | 220V /110V | |
| Power | ≤600W | |
| Rated speed | 1400rpm/1700rpm | |
| Noise | ≤65dB(A) | |
| Packing | carton case | |
| Net weight | 17.115kg | |
| Use environment | -5℃-40℃ | |
Explosion Diagram
